NEO Blockchain Quick Start Guide for .NET Developers

NEO Blockchain C# Developers Center of Excellence

The neo-csharpcoe project is an "umbrella" project for several initiatives related to providing tools and libraries (code), frameworks, how-to documentation, and best practices for enterprise application development using .NET/C#, C#.NEO and the NEO Blockchain software platform.

The neo-csharpcoe is an independent, free, open source project that is 100% community-supported by people like yourself through your contributions of time, energy, passion, promotion, and donations.

To learn more about contributing to the neo-csharpcoe, click here.

Activity 11 - Quick Cycle Edit-Compile-Debugging of C#.NEO Smart Contracts

Purpose

The purpose of this activity is to demonstrate how to use Visual Studio to rapidly edit, compile and debug C#.NEO smart contracts.

Goals, Non-Goals and Assumptions

• To reduce the time for your edit-compile-debug cycles to as short as possible.

• Assumptions

  • Your NEO development environment was setup by following the previous activities 0-10 in the NEO Blockchain Quick Start Guide for .NET Developers. This activity assumes you have an environment that conforms with the Quick Start Guide.
  • In particular, this activity is based on the following assumptions:
    • Visual Studio 2017 Community Edition has been installed
    • NeoContractPlugin Visual Studio Extension has been installed
    • Neo-compiler (neon.exe) (debugger version) is installed here:

      C:\repos\neo-debugger-tools\NEO-Compiler\bin\Debug


    • Neo-debugger is installed here:

      C:\repos\neo-debugger-tools\NEO-Debugger\bin\Debug


    • Neo-compiler (neon.exe) (regular version) is part of your search PATH environment variable

Principles

• Provide reliable documentation: timely, accurate, visual, and complete
• Save as much of a person's time as possible
• Use open source software whenever possible

Drivers

• Need in the NEO .NET developer community to have concise and easy-to-follow documentation to enable people to get up to speed developing NEO smart contracts in as short a time as possible

Quick Cycle Edit-Compile-Debugging of C#.NEO Smart Contracts: Video Tutorial

This is a tutorial intended for experienced .NET/C#/Visual Studio developers as well as those that are new to the platform. 12:28 minutes

Quick Cycle Edit-Compile-Debugging of C#.NEO Smart Contracts: Task-by-Task Tutorial

Creating and debugging a conventional Windows console application

1. Open Visual Studio. Select File -> New -> Project... in Visual Studio.



2. Select Visual C# -> Console App (.NET Framework). Enter a project name (e.g. NPC.yourname.QuickCycle.Client is recommended). Remove .Client from the solution name. Click OK to create the solution and initial Windows console app project.



   NOTE: In the future, this "Client" Windows console app project becomes the placeholder for the off-chain client/server-side app that invokes the smart contract you'll create in the "Contract" smart contract project.

3. Add the following statements to the Main method:

   Console.WriteLine("Hello world!");
   Console.ReadLine();

   Click Start to compile and debug your console application.



4. The phrase Hello World! should appear in a console window. Press Enter or click the red X to close the window and return to Visual Studio.



5. Set a breakpoint on the Console.ReadLine(); statement by clicking in the light-blue margin on the left. Click Start to compile and debug your console application a second time. When your console app stops at the breakpoint, click Continue to resume. Press Enter or click the red X to close the window and return to Visual Studio.



Creating a C#.NEO smart contract and setting it up for debugging

6. Add a NEO smart contract project to this solution by right-clicking on the solution name in Solution Explorer in Visual Studio and select Add -> New Project....



7. Select Visual C# -> NeoContract. Enter a project name (e.g. NPC.yourname.QuickCycle.Contract is recommended). Click OK to create your NEO smart contract project.



8. Right-click on the NPC.yourname.QuickCycle.Contract project in Solution Explorer and select Set as Startup Project to make the smart contract project the default project in the solution.



9. Click the Build project or Build solution icon on the Visual Studio toolbar. (Alternatively, you can right-click on the project in Solution Explorer and select Build or Rebuild).



10. Note in the Output panel in the lower-left corner Visual Studio that your smart contract was built and the NEO VM byte code (.AVM) file was created by the default (non-debugger) version of the NEO compiler (neon.exe).



11. To update the project settings to use the debugger version of the NEO compiler and to configure the NEO debugger to be launched when you click Start, right-click on the NPC.yourname.QuickCycle.Contractproject in Solution Explorer and select Properties.



12. Two sets of project properties need to be updated: Build Events and Debug.

    Click on the Build Events tab. In the Post-build event command line text box, pre-append the path where the debugger version of the NEO Compiler executable (neon.exe) can be found to the %PATH% environment variable and then invoke the compiler passing it the value of the Visual Studio $(TargetPath) environment variable. Copy and paste the following commands into the Post-build event command line text box.

    set PATH="C:\repos\neo-debugger-tools\NEO-Compiler\bin\Debug";%PATH%
    neon.exe $(TargetPath)




13. Click on the Debug tab. Click the Start external program radio button. In the Start external program text box, enter the full path name for the NEO debugger executable (neod.exe). Copy and paste the following commands ino the Start external program text box.

    C:\repos\neo-debugger-tools\NEO-Debugger\bin\Debug\neod.exe




14. In the Command line arguments text box, enter the name of your smart contract project concatenated with .avm (e.g. NPC.yourname.QuickCycle.Contract.avm). This the default name that is used by the NEO Compiler during the build process.



15. Click the X on the project's properties tab to close it.



16. Right-click on the smart contract project in Solution Explorer and select Rebuild.



17. Note that in the Output panel, two compilations have been performed as part of the build process: i) the debugger-version of the NEO Compiler ran first followed by ii) the non-debugger version of the NEO Compiler as "post-post-build" step. We need to remove the invocation of the non-debugger version of the NEO compiler.



18. Right-click on the project in Solution Explorer and select Open Folder in File Explorer.



19. We need to edit the NPC.yourname.QuickCycle.Contract.csproj C# project file to remove the post-post-build step. Right-click on the C# project file and open it with a text editor other than Visual Studio (e.g. Notepad or Visual Studio Code).



20. Scroll down to the bottom of the C# project file. Select the following lines and press Delete or Backspace to remove these lines from the C# project file.

    <Target Name="AfterBuild">
        <Message Text="Start NeoContract converter, Source File: $(TargetPath)" Importance="high">
        </Message>
        <ConvertTask DataSource="$(TargetPath)" />
    </Target>



21. Save the file and close the text editor.

    NOTE: If you used Visual Studio Code to edit the C# project file, double-check that you have saved the file before closing Visual Studio Code. Visual Studio Code will save the edited but unsaved file for you. It doesn't prompt to check if you want to save the file before closing.



22. When you return to Visual Studio, the following pop-up dialog box will appear. Click Reload to reload the C# project file. This will have no effect on your solution other than to remove the post-post-build event.



23. Right-click on the smart contract project in Solution Explorer and select Rebuild.



24. Note in the Output panel that the post-post-build event has been removed and only the debugger version of the NEO Compiler was executed.



Debugging your C#.NEO smart contract

25. To finally debug your smart contract, click Start.



26. The NEO Debugger will be launched. The source code for your smart contract should be visible in the main panel.



27. You can either press F5 to begin execution of your smart contract (without single stepping enabled) or press F10 to single-step through your contract.

    For this task, press F10 to single step through your smart contract.

    The following Invoke Smart Contract pop-up dialog will appear. Because the Main method for this smart contract doesn't accept any parameters and doesn't return any values, simple click Debug to start your debugging session.



28. Press F10 to single-step through your smart contract.



29. Continue to press F10 to single-step through your smart contract until it completes and the Execution finished pop-up appears.



    NOTE: This invocation of your smart contract consumed just over 1 GAS. Most of this was attributable to the single Storage.Put() system call in the smart contract.

30. To inspect the contents of the NEO Storage emulator implemented by the NEO Debugger, select Debug -> Storage on the debugger tool bar.



31. The following Storage pop-up dialog will appear.

    NOTE: The single key-value pair that appears in the Storage pop-up dialog is from the execution of the single Storage.Put() system call in the smart contract.



32. Click the X in the top-right corner of the debugger to close it and return to Visual Studio where you can continue to edit your smart contract project.

33. To resume the edit-compile-debug cycle by simply clicking Start in Visual Studio.

References

• [QUICKSTART] neo-csharpcoe, NEO Blockchain Quick Start Guide for .NET Developers from https://github.com/mwherman2000/neo-dotnetquickstart/blob/master/README.md
